CV Inference Serving with Triton

Overview

A portfolio project focused on deploying computer vision models with NVIDIA Triton Inference Server. The goal was to build practical experience with on-premise GPU inference serving — model optimisation, ensemble pipelines, C++ backends, and bottleneck analysis — emulating the kind of stack used in industrial CV deployments (e.g. mining, manufacturing).

The project follows a deliberate experimental arc: each experiment identifies a bottleneck, addresses it, and reveals the next one. The full progression is documented with real benchmark numbers.

Hardware & stack

• Development: laptop on WSL2, for writing code and running clients
• Inference: desktop with a GTX 1060 3GB running Ubuntu, accessed via SSH
• Serving: Docker + nvidia-container-toolkit, Triton 23.08
• PyTorch → ONNX → TensorRT FP16 (model path), C++ custom backend (preprocess), Python tritonclient HTTP/gRPC (clients), perf_analyzer + a custom load tester (benchmarking)

Pipeline

Requests arrive as raw JPEG bytes and flow through a Triton ensemble: JPEG bytes → preprocess → yolov8s_trt → postprocess → boxes / scores / class_ids.

Preprocess decodes the JPEG, letterboxes to 640×640 (preserving aspect ratio, padding with grey 114/255 as YOLOv8 expects), normalises to [0,1], and converts HWC→CHW. Postprocess applies NMS to the raw YOLOv8 output and returns bounding boxes, confidence scores, and class IDs. The input format (JPEG over HTTP) reflects a realistic industrial camera scenario: IP cameras on a mining site typically stream MJPEG or H.264, with a capture service forwarding individual frames to the inference server.

The geoclassifier model is the same one trained end-to-end in geo-classifier-quebec — this project reuses it as a second, unrelated model to test whether the serving optimisations found for YOLOv8s generalise, and to exercise multi-model deployment on the same Triton instance.

Experiments

Exp 01 — ONNX vs TensorRT FP16

Converted the YOLOv8s ONNX model to TensorRT FP16 using trtexec and compared GPU compute time and end-to-end pipeline throughput.

Model-only (GPU compute isolated, synthetic input):

TRT FP16 reduces GPU compute time by 33% and raises isolated throughput by 50%.

Pipeline (1280×720 JPEG input, 2 preprocess/postprocess instances):

The TRT advantage is visible in the pipeline (75 vs 59 inf/s), but the GPU isn’t reaching its full 88 inf/s capacity. Profiling showed Python preprocess saturates at ~87 inf/s — the partial bottleneck preventing the TRT model from running at its ceiling.

Exp 02 — C++ preprocess backend

Replaced the Python preprocess model with a custom C++ Triton backend (a compiled shared library with no Python interpreter), performing the full JPEG decode → letterbox → normalize → HWC→CHW pipeline via libjpeg-turbo.

C++ is 42% faster in latency and 31% higher in peak throughput — the key reason is the Python GIL, which serialises interpreter operations even with multiple instances. Postprocess was also measured in isolation at 332 inf/s peak, 4× above the pipeline ceiling, so no C++ replacement was needed there.

Full pipeline:

At high concurrency both pipelines converge to the same ceiling because preprocess is no longer the bottleneck — the TRT model (GPU) is. The C++ pipeline reaches that ceiling at c=3 instead of c=5, saturating more efficiently with less queuing.

Exp 03 — Dynamic batching

Re-exported the ONNX model with a dynamic batch axis and enabled Triton’s dynamic batcher (preferred batch sizes 4 and 8, 1ms queue delay).

No meaningful gain. Dynamic batching helps when a single inference leaves CUDA cores idle — i.e. the GPU has spare parallelism a larger batch can exploit. On the GTX 1060 (1152 CUDA cores), one YOLOv8s inference already saturates available compute, and GPU compute time scales roughly linearly with concurrency rather than staying flat — the signature of a GPU with no headroom. On a larger GPU (A100, V100), the same experiment would likely show a 4–8× throughput increase.

Exp 04 — Geoclassifier: ONNX vs TensorRT FP16

Repeated the ONNX vs TensorRT comparison on a second, unrelated model — geoclassifier, the EfficientNet-V2-M classifier from geo-classifier-quebec that identifies Quebec’s 17 administrative regions from street-level photos. Pipeline: C++ preprocess (resize 512 → center-crop 480 → ImageNet normalize) → model → Python postprocess (softmax → argmax, no NMS).

Model-only (GPU compute isolated):

TRT’s GPU compute time is 25% faster (28ms vs 37ms), but total latency at c=1 is 9% slower (46ms vs 42ms) — TRT carries more fixed per-request overhead (CUDA context, server I/O) that only amortises under load. Peak throughput is 35% higher with TRT.

Pipeline:

The TRT advantage carries through end-to-end (31 vs 26 inf/s peak) even though it’s slower for single requests. Pre/postprocess adds almost no overhead — only 4ms on top of the ONNX model-only latency.

Why the single-request regression matters: unlike YOLOv8s, converting this model to TRT required three separate compatibility fixes (IR version downgrade, onnxsim, re-export at opset 12) — EfficientNet-V2’s squeeze-excitation blocks aren’t cleanly supported by TRT 8.6’s ONNX importer. Combined with Pascal’s (compute 6.1) more modest FP16 gains, TRT is the right choice under load, but ONNX Runtime is better for latency-sensitive single-request serving of this model.

Bottleneck progression

From first pipeline to final: +34% throughput (59 → 79 inf/s) and -30% latency (35.6 → 25.0ms).

1. TRT helps, but the Python GIL in preprocess prevents the GPU from reaching capacity (59 → 75 inf/s, GPU alone at 88 inf/s).
2. Removing the GIL (C++ preprocess) cuts latency by 31% and closes the gap to the GPU ceiling — preprocess is no longer the bottleneck, the GPU is (79 inf/s).
3. Dynamic batching shows no gain, confirming the GPU is genuinely saturated at batch=1, not just appearing to be.

The most expensive hardware resource (GPU) ends up the limiting factor, not CPU software overhead. Tested in exp 01, gRPC vs HTTP showed no measurable difference — protocol overhead is negligible next to preprocess and GPU compute time.

This progression tracks the yolov8s detection pipeline through exp 01–03. geoclassifier (exp 04) is a separate model/track and isn’t part of the same optimisation arc — it exists to test whether the same TRT-conversion approach generalises to a different architecture.

Benchmark summary

Exp 01–03 input: 1280×720 JPEG, letterboxed to 640×640 (yolov8s). Exp 04 input: JPEG resized to 512×512 and center-cropped to 480×480 (geoclassifier).

Benchmarking

Model-only tests use perf_analyzer from the Triton SDK container; pipeline tests use a custom load tester (benchmarks/load_test.py) handling binary JPEG input over HTTP or gRPC. Full methodology, raw numbers, and analysis live in each experiment’s notes.md in the repo.
